Product info
0 Singletracks members own this.
Frame: Sortie Trail 5" 6061-T6 Weapons Grade Aluminum w/ Hydroformed Top Tube, Butted / Formed Down Tube / Seatstays, Under Arch Seatstay bridge, Knuckle Box Technology
Fork: Fox 32 Float RLC FIT Air, 130mm travel, New "FIT" Cartridge, with ext. compression / rebound / lock out knobs butted Alloy steerer, 32mm Easton aluminum stanchions, magnesium lowers, w/15mm thru axle
Rear Shock: Fox Float RP23 "XV" extra volume 200x57mm Air
Cranks: Shimano XTR Hollotech Dyna-Sys 10spd Crankset w/ XTR BB, 24/32/42t
Bottom Bracket: XTR
F. Derailleur: Shimano XTR dual pull, down swing, 34.9
R. Derailleur: Shimano XTR SGS 10spd
Shifter: Shimano XTR 10spd Rapidfire
Brake Levers: Shimano XTR, w/tool-free reach adj. free stroke adj.
Brakes: Shimano XTR Hydraulic Disc w/cooling fins, w/ 180mm frt / 160mm rear Rotors
Gear: Shimano HG980 XTR 10spd Cassette (11-36t)
Rims: Shimano XTR 24H Clincher, tubeless
Tires: WTB Wolverine 2.1 UST, Folding
Pedals: Shimano XTR clipless
Handlebar: Easton EC-70 XC CNT LoRise Carbon 31.8mm
Stem: Easton EA90 31.8mm
Seatpost: Easton EC90 CARBON Double bolt clamp 31.6mm
Seat: WTB DEVO Carbon
Headset: FSA ORBIT Z deep alloy cups, Zerostack sealed cartridge bearing 1 1/8"
Colors: Anodized Black
Chain: Shimano HG980 XTR 10spd
Hubset: (F) Shimano XTR 24H 15mm E-thru w/centerlock disc mount (R) Shimano XTR 24H cassette, QR, w/centerlock disc mount
Spokes: Shimano XTR Stainless
Grips: DB 130mm D2 Kraton
Extras: Knuckle Box Shock Pump, Sag Gauge, DB Key Chain, Owner's manual / Sortie owner's manual cover, Chainstay Protector, Clear Coat, H20 bottle mounts
